Our frictional washing machine is a special equipment for cleaning waste PET bottles, through strong friction and water rinsing, to remove the dirt, grease, label residue, and other impurities on the surface of bottle flakes.
In a plastic bottle recycling plant, the friction washer is usually located after the PET flakes hot washing machine. It removes the lye from the hot wash tank by friction washing and effectively reduces the pH value of the PET bottle flakes to ensure the purity and quality of the flakes.
Advantages of Friction Washer Plastic Recycling
Frictional washing machines offer several advantages in the plastic bottle recycling process, making them ideal for cleaning PET bottle flakes as well as other rigid flakes:
Machine Design
The body is tilted at 45 degrees, which effectively optimizes the drainage performance and ensures that the wastewater can be discharged quickly during the cleaning process to avoid secondary pollution.
Multi-purpose Washing
The frictional washing machine is not only suitable for cleaning PET bottle flakes but also can be used for cleaning HDPE, PVC, and other hard flakes, with a wide range of applicability, to meet a variety of materials cleaning needs.
Flexible Configuration
The friction washer plastic recycling is flexible in terms of location and can be configured according to the specific needs of the PET recycling line.
Efficient Washing
The interior is equipped with several friction plates to clean PET bottle flakes more thoroughly by strong friction, removing the lye brought out from the hot wash tank, effectively reducing the pH value in the bottle flakes, and ensuring the high purity of bottle flakes.
Working Process of Frictional Washing Machine
The working principle of a plastic friction washer is to utilize the friction force and the impact force of water flow to clean PET bottle flakes. When the PET bottle flakes enter the washing machine, strong friction force is generated by the high-speed rotating friction blades to remove the dirt and residue on the surface of the bottle flakes.
At the same time, the water flow in the frictional washing machine will rinse the bottle flakes and take away the detached impurities. The whole process is efficient and thorough, ensuring that the cleaned PET bottle flakes reach high purity standards.
Application of Friction Washer Plastic
Frictional washing machines are most commonly used in PET bottle washing lines, but can also be used to clean hard plastics such as HDPE PVC. It is capable of effectively removing dirt, grease, adhesives, and other impurities from the surface of plastics using efficient friction and rinsing action, ensuring the purity and quality of the plastic granules in the subsequent process.
Structure of Frictional Washing Machine
The body of the plastic friction washer consists of the mainframe, motor, stand, water inlet, inlet, and outlet. The plastic friction washing machine is mounted on an inclined frame to maximize friction and bring out impurities and contaminants.
After the material enters the friction washer, the internal friction plate cleans it thoroughly. The rotating screw pushes the material forward to the next process. The bottom of the washing machine is equipped with a sewage outlet, which can discharge sewage and debris in time to ensure the best cleaning effect.
Parameters of Plastic Friction Washer
| Mfano | SL-1000 | SL-2000 |
| Uwezo | 500-1000kg/h | 2000kg/h |
| Length | 3000mm | 3500mm |
| Nguvu | 7.5kw | 15kw |
| Out Layer | 4 mm | 4 mm |
| Unene wa blade | 6mm | 6mm |
Our equipment has various models, which can be reasonably selected according to the output. At the same time, we can also customize the machine according to the customer’s needs to ensure that the equipment can be perfectly adapted to the customer’s production line.
Recommended Plastic Bottle Recycling Equipment
If you are planning to build or upgrade a PET bottle recycling plant, Shuliy plastic friction washers are worth your consideration. Their superior performance, durability, and environmentally friendly features make them one of the top choices in the recycling industry. We highly recommend that you include a plastic bottle washer in your planning, which is an indispensable piece of equipment for a plastic bottle recycling plant.
This plastic bottle washing machine will greatly improve the efficiency of your plastic bottle recycling plant while reducing operating costs. Considering the introduction of such a machine will not only optimize the production process but will also lead to a more sustainable development of your plant.
Inquiry For Plastic Friction Washer!
Plastic bottle washing machine prices vary by model, size, and features. Shuliy, a professional plastic recycling equipment manufacturer, offers a wide range of high-quality plastic scrubbing cleaners, with prices varying depending on their performance features and customization options. You are welcome to contact Shuliy staff for detailed inquiries about plastic friction washer prices and other information, and we will be happy to provide you with personalized and customized kuchakata plastiki solutions.
